NA-9161 |
| Communication Interface Specifications |
| Number of Nodes |
99 Node / Max. |
| Expansion I/O Module |
Max. 32 Slot |
| Peripheral signal |
Input 64 bytes / Output 64 bytes |
| Indicators |
|
1 green CAN-RUN Status Indicator
1 red CAN-ERR Status Indicator
1 green/red FnBus Status Indicator
1 green Field Power supply Status Indicator |
| Communication Rate |
10 KBps~1 MBps |
| Max. bus length |
Depending on Baud rate |
| Number of PDOs available |
8 Transmit PDOs / 8 Receive PDOs |
| Number of SDOs available |
1 Standard SDOs |
| General Specification |
| System Power |
|
Supply voltage : 24Vdc nominal
Voltage range : 11~28.8Vdc |
| Power Dissipation |
100mA Typical @ 24Vdc |
| Current for I/O Module |
1.5A @ Max. 5Vdc |
| Isolation |
|
Network to Logic : Isolation
Logic to Field power : Isolation
Logic to System power : Non-isolation |
| Field Power |
|
Supply voltage : 24Vdc nominal
Voltage range : 11~28.8Vdc |
| Current in Jumper Contacts |
DC 10A Max. capacity |
| Weight |
155g |
| Module Size |
42mm X 99mm X 70mm |
